Fully Enclosed Inner Recycle Sanitary Stainless Fermentation Tank For Wine
Specifications
stainless steel grape beer fermenter, they are made of stainless steel 304 or ss316,used for grape beer production .
stainless steel grape beer fermenter
supplying range as below,
Tank (Pressure Vessel) volume: 500L-500000L
Dimension: we could design diameter and height as per customers' request
Material: Stainless Steel (304 or 316L)
Tank shell thickness: 1.5-8mm
Pressure (MPa): Atmospheric pressure-Middle pressure (According to the America Design standard)
Function: fermentation tank
Design temperature: 0-200 degree
Medium: Various drinks including wine, beer, fruit juice, and so on.
Tank surface: Mirror polished ,Matt polished ,2B
Operation plate form: We can design the platform if required.
Mixing: Top side or bottom mixing.
General accessories(If required): Manhole, CIP, respirator, sight glass, mixing
Manufacture standard: Chinese Pressure Vessel Design and Making Standard (Or America Pressure Vessel Design and Making Standard)
Guarantees inner quality and safety, good looking appearance and function by introducing international advanced large-sized equipment of pulse plasma arcwelder and auto polishing machines and cooperating with international famous finished
Main parameters:
| Item | Volume | A | B | C | D | E | F | G |
| ZTFV-04 | 400L | 950 | 1090 | 500 | 750 | 165 | 320 | 2220 |
| ZTFV-06 | 600L | 950 | 1090 | 500 | 1000 | 165 | 320 | 2470 |
| ZTFV-08 | 800L | 1100 | 1240 | 500 | 1030 | 175 | 351 | 2561 |
| ZTFV-1 | 1000L | 1270 | 1410 | 500 | 1030 | 195 | 386 | 2636 |
| ZTFV-1.5 | 1500L | 1270 | 1410 | 500 | 1390 | 195 | 386 | 3096 |
| ZTFV-2 | 2000L | 1400 | 1540 | 500 | 1460 | 225 | 413 | 3223 |
| ZTFV-3 | 3000L | 1600 | 1740 | 500 | 1670 | 255 | 455 | 3505 |
| ZTFV-4 | 4000L | 1850 | 1990 | 500 | 1700 | 305 | 506 | 3636 |
| ZTFV-6 | 6000L | 1850 | 1990 | 500 | 2470 | 305 | 506 | 4406 |
| ZTFV-10 | 10000L | 2150 | 2315 | 500 | 2970 | 340 | 568 | 5268 |
| ZTFV-15 | 15000L | 2450 | 2615 | 500 | 3400 | 360 | 631 | 5781 |
| ZTFV-20 | 20000L | 2850 | 3015 | 500 | 3400 | 380 | 714 | 5884 |
Why Choose Us:
Specialist manufacturer
We have own factory,we get CE certification,Special equipment pressure vessel manufacturing license.We specialize in manufacturing beer brewing equipment.
2.Quality and price
We have professional purchasing team. Comparing multiple vendors,then choose
best raw materials and the most preferential price. We have skilled worker and
strict quality control system,provide the best quality products to our customers.
3.Convenient transportation
Our company is located in Wenzhou Zhejiang,which is near Shanghai port and Ningbo port. It just take 5 hours from shanghai to our factory and take 3 hours
from Ningbo to our factory.
4.Clear order process
We have clear order process. From mails &calling→→order confirmed →→make advance payment→→workshop produce→→pay the balance→→deliver goods→→buyers receiving confirmation→→satisfaction survey.
5.Quality of service
We will provide photos to make our customers know the order status. Of course,we welcome our customers to our factory to inspect any time!
Certificate
